6.40
16.00
6.50
4.80
3.40
1.70
4.30
0.5~1.5
0.75
19
#8
4.3
技術數(shù)據(jù)說明
型號Item No |
導線截面（mm2） |
材料厚度（mm） |
最大電流（A） |
美制螺栓號 |
螺栓口直徑 |
尺寸 |
購買操作 |
W |
L |
F |
E |
Dφ |
dφ |
| SNB1.25-3 |
0.5~1.5 |
0.75 |
19 |
#4 |
3.2 |
5.7 |
16.0 |
6..5 |
4.8 |
3.4 |
1.7 |
|
| SNB2-3 |
1.5~2.5 |
0.8 |
27 |
#4 |
3.2 |
5.7 |
16.0 |
6.5 |
4.8 |
4.1 |
2.3 |
|
| SNB3.5-4 |
2.5~4 |
1.0 |
37 |
#8 |
4.3 |
7.2 |
18.3 |
7.0 |
6.0 |
5.0 |
3.0 |
|
| SNB3.5-5 |
2.5~4 |
1.0 |
37 |
#10 |
5.3 |
8.0 |
18.3 |
7.0 |
6.0 |
5.0 |
3.0 |
|
| SNB1.25-3.5S |
0.5~1.5 |
0.75 |
19 |
#6 |
3.7 |
5.7 |
16.0 |
6.5 |
4.8 |
3.4 |
1.7 |
|
| SNB1.25-3.5L |
0.5~1.5 |
0.75 |
19 |
#6 |
3.7 |
6.4 |
16.0 |
6.5 |
4.8 |
3.4 |
1.7 |
|
| SNB1.25-4S |
0.5~1.5 |
0.75 |
19 |
#8 |
4.3 |
6.4 |
16.0 |
6.5 |
4.8 |
3.4 |
1.7 |
|
| SNB1.25-4M |
0.5~1.5 |
0.75 |
19 |
#8 |
4.3 |
7.2 |
16.0 |
6.5 |
4.8 |
3.4 |
1.7 |
|
| SNB1.25-4L |
0.5~1.5 |
0.75 |
19 |
#8 |
4.3 |
8.1 |
16.0 |
6.5 |
4.8 |
3.4 |
1.7 |
|
| SNB1.25-5S |
0.5~1.5 |
0.75 |
19 |
#10 |
5.3 |
8.1 |
16.0 |
6.5 |
4.8 |
3.4 |
1.7 |
|
| SNB1.25-5L |
0.5~1.5 |
0.75 |
19 |
#10 |
5.3 |
9.5 |
16.0 |
6.5 |
4.8 |
3.4 |
1.7 |
|
| SNB2-3.5S |
1.5~2.5 |
0.8 |
27 |
#6 |
3.7 |
5.7 |
16.0 |
6.5 |
4.8 |
4.1 |
2.3 |
|
| SNB2-3.5L |
1.5~2.5 |
0.8 |
27 |
#6 |
3.7 |
6.2 |
16.0 |
6.5 |
4.8 |
4.1 |
2.3 |
|
| SNB2-4S |
1.5~2.5 |
0.8 |
27 |
#8 |
4.3 |
6.4 |
16.0 |
6.5 |
4.8 |
4.1 |
2.3 |
|
| SNB2-4M |
1.5~2.5 |
0.8 |
27 |
#8 |
4.3 |
7.2 |
16.0 |
6.5 |
4.8 |
4.1 |
2.3 |
|
| SNB2-4L |
1.5~2.5 |
0.8 |
27 |
#8 |
4.3 |
8.1 |
16.0 |
6.5 |
4.8 |
4.1 |
2.3 |
|
| SNB2-5S |
1.5~2.5 |
0.8 |
27 |
#10 |
5.3 |
8.1 |
16.0 |
6.5 |
4.8 |
4.1 |
2.3 |
|
| SNB2-5L |
1.5~2.5 |
0.8 |
27 |
#10 |
5.3 |
9.5 |
16.0 |
6.5 |
4.8 |
4.1 |
2.3 |
|
| SNB3.5-6 |
2.5~4 |
1.0 |
37 |
1/4 |
6.4 |
12.0 |
21.5 |
12.1 |
6.0 |
5.0 |
3.0 |
|
| SNB5.5-6S |
4~6 |
1.0 |
48 |
1/4 |
6.4 |
9.0 |
19.5 |
7.5 |
6.8 |
5.6 |
3.4 |
|
| SNB5.5-6L |
4~6 |
1.0 |
48 |
1/4 |
6.4 |
12.0 |
25.5 |
12.0 |
6.8 |
5.6 |
3.4 |
|
| SNB5.5-8 |
4~6 |
1.0 |
48 |
5/16 |
8.4 |
14.0 |
24.5 |
11.5 |
6.8 |
5.6 |
3.4 |
|
-
